Power: 60-200W
Voltage: 100-240VAC
Lumens: 6900-23000lm
Color: 2800-3300K/4000-4500K/5500-6000K
Beam Angle: 60°/120°
Warranty: 36 Months
COB LED Luces del túnel podría ser utilizado en todos los tipos de túneles. A medida que el flujo luminoso podría ser de 6900lm-23000lm, podrían reemplazar todas las lámparas tradicionales de HID con la COB LED Luces del túnel.
COB LED Luces del túnel podría ser utilizado en todos los tipos de túneles. A medida que el flujo luminoso podría ser de 3500lm-1600lm, podrían reemplazar todas las lámparas HID tradicionales con alta lux y vida útil más larga.
Iluminación LED para túneles se aplica sobre todo en tienda de la ropa, librería, tienda, Holtel, edificio, pared del hotel, aquare opinión de la noche, la iluminación del paisaje, decoración de interiores, reflector al aire libre y otros lugares donde se requieren ahorro de energía, verde, con poco carbono de la luz LED.
LED Característica luz de túnel:
1.80% energy saving compare with traditional light .
2.Energy saving, Environment friendly, No UV and Mercury, be comply with ROHS.
3.Wide input voltage (AC85-265V), High switch-on/off, short time for pulse-on, no stroboflash.
4.Using of high brightness LED chip and adopt radiation heat dissipation method to ensure LED efficiency,longlifespan.
5.Insulated low voltage LED driver, Have overvoltage surge, short circuit, overload protection function,Safty, raliable.
6.Using single constant current switching power to supply LED power supply mode., ensure LED light source on stable working.
7.No flicker, no glare even swich-on/off frequently. --High CRI, good for anti-seismic, nice apperance, -easy forinstallation and transportation.
| No. | Pictures | Model No. | Power (W) |
Lumen (LM) |
Beam Angle |
Input Voltage |
Color |
| 1 |  |
ENTL-60W-01 | 60 | 6900 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 2 | |
ENTL-80W-01 | 80 | 9200 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 3 | |
ENTL-100W-01 | 100 | 11500 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 4 |  |
ENTL-100W-02 | 100 | 11500 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 5 | |
ENTL-120W-02 | 120 | 13800 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 6 | |
ENTL-140W-02 | 140 | 16100 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 7 |  |
ENTL-120W-03 | 120 | 13800 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 8 | |
ENTL-150W-03 | 150 | 17250 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 9 |  |
ENTL-160W-04 | 160 | 18400 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 10 | |
ENTL-200W-04 | 200 | 23000 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 11 | |
ENTL-60W-01MW | 60 | 6900 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 12 | |
ENTL-80W-01MW | 80 | 9200 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 13 | |
ENTL-100W-01MW | 100 | 11500 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 14 | |
ENTL-100W-02MW | 100 | 11500 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 15 | |
ENTL-120W-02MW | 120 | 13800 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 16 | |
ENTL-140W-02MW | 140 | 16100 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 17 | |
ENTL-120W-03MW | 120 | 13800 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 18 | |
ENTL-150W-03MW | 150 | 17250 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 19 | |
ENTL-160W-04MW | 160 | 18400 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
| 20 | |
ENTL-200W-04MW | 200 | 23000 | 60°/120° | 100-240VAC | 2800-3300K/ 4000-4500K/ 5500-6000K |
